| 产品型号 | 功率 | 输入电压 | 输出电压 | 输出电流 | 效率 | 密闭封装尺⼨(mm) | 是否全国产化 |
|---|---|---|---|---|---|---|---|
| Q250-24S05M-G | 250W | 18-36VDC | 5V | 50A | 91% | 60.8*39.2*13.0 | 是 |
| Q300-24S12M-G | 300W | 18-36VDC | 12V | 25A | 92% | 62.1*41.0*13.0 | 是 |
| Q400-24S28M-G | 400W | 18-36VDC | 28V | 14.3A | 92% | 62.1*41.0*13.0 | 是 |
| Q400-28S28M-G | 400W | 16-40VDC | 28V | 14.3A | 92% | 62.1*41*13.0 | 是 |
| Q350-28S28M-G | 350W | 16-40VDC | 28V | 12.5A | 92% | 62.1*41*13.0 | 是 |
| Q300-28S24M-G | 300W | 16-40VDC | 24V | 12.5A | 92% | 62.1*41*13.0 | 是 |
| Q250-270S05M-G | 250W | 180-425VDC | 5V | 50A | 90% | 61.4*39.7*13.0 | 是 |
| Q300-270S12M-G2 | 300W | 180-425VDC | 12V | 25A | 91% | 61.4*39.7*13.0 | 是 |
| Q300-270S28M-G | 300W | 180-425VDC | 28V | 10.7A | 92% | 61.4*39.7*13.0 | 是 |
