| 序号 | 功率 | 输⼊电压 | 输出电压 | 输出电流 | 效率 | 密闭封装尺⼨(mm) | 是否全国产化 |
|---|---|---|---|---|---|---|---|
| 24Vin | |||||||
| 1 | 250W | 18-36VDC | 5V | 50A | 91% | 60.8*39.2*13.0 | 是 |
| 2 | 300W | 18-36VDC | 12V | 25A | 92% | 60.8*39.2*13.0 | 否 |
| 3 | 400W | 18-36VDC | 28V | 14.3A | 92% | 62.1*41.0*13.0 | 是 |
| 28Vin | |||||||
| 4 | 300W | 16-40VDC | 24V | 12.5A | 92% | 62.1*41*13.0 | 是 |
| 5 | 350W | 16-40VDC | 28V | 12.5A | 92% | 62.1*41*13.0 | 是 |
| 6 | 400W | 16-40VDC | 24V | 16.7A | 92% | 62.1*41*13.0 | 是 |
| 7 | 400W | 16-40VDC | 28V | 14.3A | 92% | 62.1*41*13.0 | 是 |
| 48Vin | |||||||
| 8 | 350W | 36-75VDC | 28V | 12.5A | 92% | 62.1*41*13.0 | 否 |
| 270Vin | |||||||
| 9 | 250W | 180-425VDC | 5V | 50A | 90% | 61.4*39.7*13.0 | 是 |
| 10 | 300W | 180-425VDC | 12V | 25A | 91% | 61.4*39.7*13.0 | 是 |
| 11 | 300W | 180-425VDC | 28V | 10.7A | 91% | 61.4*39.7*13.0 | 是 |
