| 产品型号 | 功率 | 输入电压 | 输出电压 | 输出电流 | 效率 | 密闭封装尺⼨(mm) | 是否全国产化 |
|---|---|---|---|---|---|---|---|
| H600-28S12PM-G2 | 600W | 16-40VDC | 12V | 50A | 91% | 63.2*60.6*13.0 | 是 |
| H700-28S28PM-G | 700W | 16-40VDC | 28V | 25A | 92% | 63.2*60.6*13.0 | 是 |
| H700-28S24PM-G | 700W | 16-40VDC | 24V | 29.1A | 92% | 63.2*60.6*13.0 | 是 |
| H500-270S12PM-G | 500W | 180-425VDC | 12V | 41.7A | 93% | 63.2*60.6*13.0 | 是 |
| H500-270S24PM-G | 500W | 180-425VDC | 24V | 20.8A | 94% | 63.2*60.6*13.0 | 是 |
| H500-270S28PM-G | 500W | 180-425VDC | 28V | 17.9A | 94% | 63.2*60.6*13.0 | 是 |
| H600-540S28PM-G | 600W | 400-650VDC | 28V | 21.5A | 94% | 63.2*60.6*13.0 | 是 |
| H600-540S36PM-G | 600W | 400-650VDC | 36V | 16.7A | 94% | 63.2*60.6*13.0 | 是 |
| H500-24S12PM | 500W | 18-36VDC | 12V | 41.7A | 90% | 63.2*60.6*13.0 | 否 |
| H500-24S28PM | 500W | 18-36VDC | 28V | 17.9A | 92% | 63.2*60.6*13.0 | 否 |
| H600-24S28PM | 600W | 18-36VDC | 28V | 21.4A | 92% | 63.2*60.6*13.0 | 否 |
| H700-24S28PM | 700W | 18-36VDC | 28V | 25A | 92% | 63.2*60.6*13.0 | 否 |
| H600CR-28S60PM | 600W | 16-40VDC | 60V | 10A | 92% | 63.2*60.6*13.0 | 否 |
| H700CR-28S28PM | 700W | 16-40VDC | 28V | 25A | 92% | 63.2*60.6*13.0 | 否 |
| H600-150S24PM | 600W | 90-210VDC | 24V | 25A | 92% | 63.0*60.5*13.0 | 否 |
