| 序号 | 功率 | 输⼊电压 | 输出电压 | 输出电流 | 效率 | 密闭封装尺⼨(mm) | 并联数量 | 是否全国产化 |
|---|---|---|---|---|---|---|---|---|
| 24Vin | ||||||||
| 1 | 100W | 18-36VDC | 5V | 20A | 91% | 58.0*36.8*13.0 | 3 | 否 |
| 2 | 100W | 18-36VDC | 12V | 8.4A | 91% | 58.0*36.8*13.0 | 3 | 否 |
| 3 | 150W | 18-36VDC | 24V | 6.25A | 92% | 61.7*26.5*12.7 | / | 否 |
| 4 | 150W | 18-36VDC | 5V | 30A | 92% | 61.7*26.5*12.7 | / | 是 |
| 5 | 150W | 18-36VDC | 12V | 12.5A | 93% | 61.7*26.5*12.7 | / | 是 |
| 6 | 150W | 18-36VDC | 28V | 5.3A | 92% | 61.7*26.5*12.7 | / | 是 |
| 48Vin | ||||||||
| 7 | 200W | 36-75VDC | 5V | 40A | 91% | 58.0*36.8*13.0 | / | 否 |
| 8 | 250W | 36-75VDC | 28V | 8.9A | 93% | 58.0*36.8*13.0 | / | 否 |
| 270Vin | ||||||||
| 9 | 150W | 180-425VDC | 5V | 30A | 91% | 61.7*26.5*12.7 | / | 是 |
| 10 | 150W | 180-425VDC | 12V | 12.5A | 92% | 61.7*26.5*12.7 | / | 是 |
